Dynaudio Confidence 20

Beschrijving / Description

Like the rest of the range, the Confidence 20 features the 28mm Esotar3 soft-dome tweeter, plus an improved 18cm NeoTec MSP woofer and an innovative down-firing bass port.

Its drivers feature cutting-edge developments in airflow technology (including a much larger rear chamber and optimised venting in the tweeter, plus the resonance-stabilising Hexis inner dome); simulation-derived diaphragm thickness; super-powerful neodymium magnets; and the Compex front baffle.

The 28mm Esotar3 soft-dome tweeter takes over 40 years of Dynaudio expertise, plus plenty of learnings from the award-winning Esotar Forty unit and rolls it all into the finest tweeter we've ever created. A powerful neodymium magnet system, innovations in airflow routing, the resonance-busting Hexis inner dome it all combines to increase detail, clarity and sensitivity.

The 18cm NeoTec MSP woofer also has neodymium under the hood, and uses glass-fibre in its voice-coil former for optimum stiffness. The voice-coil itself is aluminium, which lets us use the ideal weight (or lightness, depending on your point of view) for powerful and controlled bass as well as refined midrange. And the entire woofer motor has been designed to harness airflow using an innovative venting system that's been machined directly into the magnet.




Klik op de afbeelding voor een vergroting
Click picture for magnification

Specificaties / Specifications

Type Bookshelf INCLUDING STANDS
Sensitivity (dB @ 2.83V/1m) 87
IEC Power Handling (Watt) 250
Rated Impedance (Ohm) 6
Minimum Impedance (Ohm) 5 ohm @ 155 Hz
Lower Cutoff (Hz @ +/- 3 dB) 42
Upper Cutoff (kHz @ +/- 3 dB) 22
Box Principle Bass reflex down-firing port
Crossover 2-way
Crossover Frequency (Hz) 2325 Hz
Crossover Topology 2nd order
Tweeter 28 mm Esotar 3
Midrange/Woofer 18 cm MSP
Weight kg 27
Weight lbs 59 4/8
Width mm 233
Height mm 520
Depth mm 414
Width inches 9 1/8
Height inches 20 4/8
Depth inches 16 2/8
Width mm incl. feet/grill 223
Height mm incl. feet/grill 520
Depth mm incl. feet/grill 444
Width inches incl. feet/grill 8 6/8
Height inches incl. feet/grill 20 4/8
Depth inches incl. feet/grill 17 4/8

Staat van artikel
Nieuw

Prijs
€ 11.000,00 (per set)
