Equipped with two 6 inch C-CAM bass drivers, a 6 inch C-CAM mid driver, and a 1 inch Gold Dome C-CAM tweeter, the floor-standing RS8 is the latest incarnation of a true giant-killer.
Advanced tweeter design providing smoother character with increased clarity.
C-CAM cone profile for better damping and improved mid-range clarity.
Bass chassis design for better rigidity and damping properties.
Improved bass performance with high efficiency.
High quality crossovers.
Matching drivers in all models for better integration and system building.
Real wood veneer top bottom.
Klik op de afbeelding voor een vergroting
Click picture for magnification
Frequency Response 33 Hz - 30 KHz
Sensitivity (1W@1M) 91 dB
Nominal Impedance 6 Ohms
Power Handling (RMS) 175 W
Recommended Amplifier Requirements 40-175 W
Crossover Frequency 3 KHz
Drive Unit Complement
2 x 6 inch C-CAM Bass Drivers.
1 x 6 inch C-CAMMid-range Driver.
1 x 1 inch (25 mm) gold dome C-CAM tweeter.
Cabinet Support Balanced velocity twin reflex ported
External Dimensions (H x W x D)
900 x 185 x 270 mm (35 1/2 x 7 1/4 x 10 5/8 inch)
Plinth Dimensions (H x W x D)
25 x 255 x 325 mm (1 x 10 x 12 13/16 inch)
Weight (each) 21 Kg (46.2 lb)
