Toshiba SA-620

AM/FM Stereo Receiver (1977)

Previous Next

Klik op de afbeelding voor een vergroting
Click picture for magnification

Tuning range: FM, MW
Power output: 55 watts per channel into 4 ohm (stereo)
Frequency response: 15Hz to 40kHz
Total harmonic distortion: 0.4%
Damping factor: 45
Input sensitivity: 2.5mV (MM), 150mV (DIN), 150mV (line)
Speaker load impedance: 4 to 16 ohm
Semiconductors: 6 x FET, 2 x IC, 42 x transistors, 26 x diodes
Dimensions: 530 x 158 x 435mm
Weight: 18.5kg
