Bang And Olufsun BEOLAB 1

Launched in 1999, the BeoLab 1 was the successor to the popular Penta series and was Bang & Olufsen's flagship loudspeaker until the launch of the BeoLab 5 in 2004.

With 750w on tap (per speaker), the BeoLab 1 are incredibly powerful and are ideal for use as stereo monitors (with an audio system) or as front surround speakers in a Dolby Surround Sound system.

Previous Next

Klik op de afbeelding voor een vergroting
Click picture for magnification

Dimensions Height 1843 mm
Foot 398 mm,
Weight 36 kg
Power Consumption IEC65: 40 W
Typical: 14 W
Stand-by: <0.5 W
Maximum Sound Pressure Level 105 dB (stereo, pair)
Power amplifiers 3 units, Bass part Class D, Midrange/Treble part Class AB
Long-term maximum output power per amplifier Bass: 450 W/4ohm
Midrange: 125 W/8ohm
Treble: 125 W/8ohm Effective Frequency range 39 - 20,000 Hz
Cabinet principle Closed box
Magnetically shielded Yes
Woofers 2 x 16.5 cm
Midrange 7.6 cm
Tweeter 2.5 cm
Net volume 16 litres
Bass equalization ABL (Adaptive Bass Linearization)
Switch for loudspeaker position: Freestanding Against Wall In Corner
Input sensitivity (line) 125 mV (91dB SPL) Auto switch on
Input sensitivity (Power Link) 125 mV (91dB SPL)
Switch off time (line) 3 min.

Connections:
Power Link 2
Phono (line) 1
