Specificaties / Specifications
D/A Conversion
Theorical Resolution : 24 Bits > 192 KHz samples Rates
Resampling Rate : 384 Fs
D.A.C Architecture : Delta-Sigma Modulation
Power Bandwidth : 5 Hz to 24 KHz +/- 0,0015 dB
Channel Isolation : - 125 dB
Channel-to-channel phase error : N mesurable
Noise/Signal Ratio : - 130 dB
A weighted noise/signal Ratio : - 160 dB
Phase linearity : +/- 0.19"
Unbalanced Analog Output Voltage : 3,30 V
Balanced Analog Output Voltage : +/- 1,65 V
Characteristics
Technical features
CD Mechanism : L1210 / Gyropoint II
Loader Type : Front Loader
Weight : 7 kg
Optical Features
Data Beams : 3
Servo Beams : 2
RF Data Flow : Integrated Amplifier
Engines
Drive Method : PWM Digital Servo
Slide Method : PFM Digital Servo
Disc Diameter : 80/120 mm
Digital Output
S/P DIF Coaxiale via RCA : 0,5 V p-p, 75 ohms
Zoek eventueel via het menu of via Ebay of Marktplaats!
Item possibly sold.
Search via menu or via Ebay or Marktplaats!
