Gold Note PH-5

The PH-5 is the latest born at Gold Note's range of phono stages, designed to deliver the same high quality and excellent performance that made the PH-10 and PH-1000 famous, with an affordable price and all the cutting-edge features that stands out our products. With a single RCA input, it can be connected to either MM or MC cartridges and offers an EQ curves selection (RIAA, Decca London and American Columbia, with Enhanced option), as well as the LOAD's and GAIN's adjustments to guarantee the utmost flexibility and versatility, making it perfect for every kind of analogue system.

The PH-5 is the first Gold Note product designed with a touchscreen interface: all the settings are easily accessible and changeable thanks to the innovative and unparalleled user-friendly display that allows you to select and manage all the options in real time while playing your music. The phono stage is based on a completely new design to integrate the whole electronics into a single board.

Previous Next

Klik op de afbeelding voor een vergroting
Click picture for magnification

EQ CURVES 3 EQ curves (RIAA, Decca London, American Columbia) all with Enhanced option
ANALOG INPUTS 1 RCA MM/MC
ANALOG OUTPUTS 1 RCA
1 XLR
OUTPUT IMPEDANCE 50 ohm
SUBSONIC FILTER 10Hz/36dB octave
TOTAL HARMONIC DISTORTION THD <0.05% @ 1kHz
SIGNAL TO NOISE RATIO 89dB
DYNAMIC RESPONSE 105dB
FREQUENCY RESPONSE 20Hz - 20KHz +/- 0.3dB
