Heed Quasar Phono mm-mc with PSU

Beschrijving / Description

See review link.

Klik op de afbeelding voor een vergroting
Click picture for magnification

Specificaties / Specifications

Solid-state moving-coil/moving-magnet phono preamplifier with standalone power supply.
RIAA accuracy: 20Hz-20kHz, +/-0.5dB.
Frequency response: 3Hz-150kHz, +/-3dB.
Voltage gain: 50dB (MM), 62-78dB (MC).
Moving-coil sensitivity: 100, 220, 600uV.
Input impedance: 47k ohms (MM); 100/470/1000 ohms (MC).
Output voltage: High Out, 775mV (0dBm)/22 ohms; Low Out, 220mV/100 ohms.
Maximum output voltage: 7V (p-p).
Output impedance: 50 ohms (High Out), 600 ohms (Low Out).
Signal/noise (A-weighted): 80dB (MM), 66dB (MC).
Channel separation: >90dB.
Distortion (THD, 1kHz, 100mW): <0.08%.
Power consumption: <10W.
Dimensions: Quasar Q-PSU power supply (each): 3.75" (95mm) W by 3" (75mm) H by 8.7" (220mm) D.
Weight (combined): 6.6 lbs (3kg).
