Marantz CD94 MK2

Heavyweight CD Player (1987-90)
The superb audiophile performance of the Marantz CD-94 is based on the proven superiority of the full 16-bit 4-times oversampling digital filter. It is characterised by very low distortion and almost no phase error.

A vital factor in the performance of the CD-94 is an accurate read-out of the disc. The CDM-1 mechanism, made of diecast aluminium, provides rigid support for the laser pick-up. The complete assembly is floated off the main chassis on massive rubber dampers; a suspension system that assures freedom from vibration and acoustic feedback.

Furthermore, the mechanical control circuits have been separated from the CDM-1 mechanism to avoid magnetic interference in the control circuitry and possible vibration from the drive mechanism.

Previous Next

Klik op de afbeelding voor een vergroting
Click picture for magnification

Disc format: CD
Digital converter: 2 x TDA1541A-S1, 16 bit linear
CD Mechanism: CDM-1
Frequency response: 2Hz to 20kHz
Dynamic range: 96dB
Signal to Noise Ratio: 101dB
Channel separation: 100dB
Total harmonic distortion: 0.0015%
Line output: 2V
Digital connections: coaxial, optical
Dimensions: 462 x 86 x 333mm
Weight: 12.5kg
Accessories: RC-94IICD remote control
