Pro-Ject XTension 9 EVO Superpack
Beschrijving / Description
Xtension 9
Highend turntable with 9 inch EVO tonearm, Ortofon Quintet Black
Version of the Xtension 9 model but including the Ortofon Quintet Black cartridge (MC - Moving Coil Cartridge) in Piano Black, Mahogany or Olive finishes.
Project XTENSION 9 turntable with Ortofon Quintet Black cartridge. Project has been manufacturing turntables for over 20 years, and has accumulated a wealth of mechanical and electronic technology and brilliant solutions for analogue playback, which it applies to all of its products. It also manufactures turntables for other well-known and highly-regarded companies that use Project's sophisticated technology.
Well, Project applies all of this to the new XTENSION 9 turntable. The electronic motor is assisted by a circuit that also controls the speeds of 33, 45 and 78 rpm. This motor drives the platter made of a sandwich of various materials by means of a flat rubber belt around the perimeter. The main chassis is a system that Project calls sub chassis with floating magnetic charge. This prevents vibrations from reaching the arm/capsule and degrading the sound quality. The platter rests on a magnetic system that raises it a few millimetres above the transmission shaft. This shaft incorporates a precision ceramic bearing. This magnetic suspension of the platter also prevents friction on the vertical axis of the transmission, thus achieving greater rotational precision and preventing vibrations from being transmitted to the vinyl record.
Heavy 16 kg belt drive turntable
Mass loaded magnetic floating subchassis
Precision balanced sandwich-platter
Inverted ceramic ball bearing with magnetic support
Heavy weight record clamp
MDF chassis filled with metal granulate with low levels of resonance and high mass
Electronic speed control 33/45 rpm
Tonearm 9cc Evolution made from carbon fiber
Inverted tonearm bearings (ABEC 7 quality)
Specificaties / Specifications
Speed 33 / 45 rpm (electronic speed change)
Acrylic dust cover yes
Pro-Ject tonearm cable included Connect it 5P-C
Aluminum feet Magnetic supported & TPE damped
Turntable main bearing damping heavy weight metal block
Max. speed variance +/-0.09%
Max. wow and flutter +/-0.01%
Rumble -71dB
Platter weight/diameter 5.4 kg/300mm
Platter puck weight 800gr
Effective arm length / overhang 230mm / 18mm
Effective tonearm mass 8.5g
Tracking force range 0-25mN
Cartridge weight range 4 - 14g (4 different counterweights included)
External power supply (prim/sec) 220 - 240V/50Hz / 15V/1600mA DC
Power consumption 4W (max.) / < 1 watt standby Measurements Width 465 x Height 185 x Depth 350mm (lid closed)
Weight 16Kg
