Rega Fono MM MK5

The Fono MM MK5 phono stage has been designed to be effective, easy to use and above all, to reproduce music. The Fono MM MK5 uses a fully discrete, cascaded, complementary amplifier input stage, a configuration designed to optimise the performance of your moving magnet cartridge. Now housed in a brand new redesigned case to match the new Fono MC and Rega's latest range of electronic components offering a modern look guaranteed to integrate in to any hi-fi system.

Previous Next

Klik op de afbeelding voor een vergroting
Click picture for magnification

Input Sensitivity 1.7 mV for 200 mV Output
Input Loading 47 kohm in parallel with 100 pF
Maximum Input Level 60 mV at 1 kHz
Gain 41.4 dB at 1 kHz
Output Impedance 200 ohm
Recommended Minimum Output Load Resistance 5 k ohm
Frequency response (50K ohm output load) 15 Hz (-3 dB) to 100 kHz (-0.2 dB)
RIAA Accuracy (50 k ohm Output Load) Better than +/-0.2 dB 100 Hz to 100 kHz
Power Requirements 24 V AC at 80 mA maximum
