Stereo Integrated Amplifier (1965-69)
Klik op de afbeelding voor een vergroting
Click picture for magnification
Power output: 40 watts per channel into 8 ohm (stereo)
Frequency response: 20Hz to 50kHz
Total harmonic distortion: 0.8%
Damping factor: 15
Input sensitivity: 220mV (line)
Signal to noise ratio: 70dB (MM), 80dB (line)
Channel separation: 45dB (MM), 50dB (line)
Output: 2.1V (Pre out)
Speaker load impedance: 8 to 16 ohm
Dimensions: 460 x 170 x 345mm
Weight: 24.5kg
