Teac PE-505

Fully-balanced Phono Amplifier

Previous Next

Klik op de afbeelding voor een vergroting
Click picture for magnification

Amplifier section
Total harmonic distortion (Rated output, 1kHz, GAIN Low)
RCA input (MM) 0.002%
RCA input (MC) 0.02%
XLR input (MC) 0.02%
Residual noise volt (Input short, GAIN low, IHF-A)
RCA input (MM) 10uV
RCA input (MC) 65uV
XLR input (MC) 85uV
S/N ratio (Input short, Rated input, GAIN Low, IHF-A)
RCA input (MM) 106dB
XLR input (MC) 86dB
RIAA deviation (20Hz to 20kHz) +/-0.05dB
Channel separation 90dB or higher (MM, 10kHz, GAIN Low)
Gain
GAIN LOW
RCA input (MM) 34dB
RCA input (MC) 54dB
XLR input (MC) 54dB
GAIN HIGH
RCA input (MM) 46dB
RCA input (MC) 66dB
XLR input (MC) 66dB
Subsonic filter 17Hz, 24dB/octave
Phono input section
Unbalanced input RCA Pin (MC/MM compatible) x 1 pair
Max input level 150mV (MM, THD 0.1%, GAIN Low)
16mV (MC, THD 0.1%, GAIN Low)
Input impedance
MM 47k ohm, Load-impedance: 0, 100, 220, 330pF
MC 10, 22, 47, 100, 220, 470, 1k ohm
Balanced input XLR (MC only) x 1 pair
Max input level 16mV (MC, THD 0.1%, GAIN Low)
Input impedance
MC 10, 22, 47, 100, 220, 470, 1k Ohm switchable from the Settings
Analog output section
Unbalanced output RCA pin x 1 pair
Rated output level 2Vrms
Output impedance 63 ohm
Balanced output XLR x 1 pair
Rated output level 4Vrms
Output impedance 126 ohm
Power supply
AC120V, 60Hz

AC220 - 240V, 50/60Hz

Power consumption 14W
Overall dimensions(W x H x D) 290 x 84.5 x 252.5 mm / 11.4" x 3.3" x 9.9"
Weight 4.5kg / 10.0 lbs.
